Manley 596810C-8 Platinum Series Forged Pistons 4.100" Bore Chevy LS

The Manley 596810C-8 Platinum Series forged piston set delivers professional-grade performance for Chevy LS engine builds. Engineered for LS-1, LS-2, LS-3, LS-6, LS-7, and LS-92 applications, these pistons are designed for stroker builds using a 4.135" stroke with 6.125" connecting rods and a 4.100" bore.

Key Features:

• Forged from 2618 high-strength aluminum alloy for superior durability
• Lightweight design at 432 grams (piston only) for improved engine response
• Moly-coated skirts reduce friction and wear
• 1.5mm x 1.5mm x 3mm ring package for excellent ring seal
• 0.175" trough design machined for reluctor wheel clearance
• Offset wrist pin design for quieter operation
• Forced pin oiling, pressure balance groove, and precision pin fitting
• 0.927" diameter wrist pin with 1.065" compression height
• Premium Chrome Moly wrist pins and round wire locks included

Manley's unique fixturing process machines the skirt and ring grooves in a single operation, ensuring perfect ring groove to skirt squareness for maximum horsepower and optimal ring seal.
