DeatschWerks 9-301-UX1 Universal UX1 Fuel Pump Module with DW300 340LPH Pump

The DeatschWerks 9-301-UX1 is a universal X1 Series in-tank fuel pump module with bucket and DW300 fuel pump. It suits custom builds, EFI conversions and retrofits. It also suits vehicles that have no OEM in-tank pump and are being upgraded to modern EFI fueling. The module is built for one pump and has a return fuel line, an integrated surge bucket and venturi siphon functionality.

Key Features:

• DW300 fuel pump that flows 340 LPH at 40 psi
• Billet aluminum construction
• Integrated surge bucket for slosh-free performance
• Built-in venturi siphon system to help prevent fuel starvation
• 8AN ORB feed with low profile swivel fitting
• 6AN ORB return with low profile swivel fitting
• Optional 4AN ORB vent, with a 5/16" barb fitting included
• Universal cut-to-fit design that accommodates fuel tanks up to 20" deep
• Includes top-hat, gasket, support tube, installation kit and bucket

This is a universal module, so some adaptation may be required to fit your tank and application.
