RADIUM Engineering 20-1170 Fuel Pump Hanger for BMW E36

The RADIUM Engineering 20-1170 is a complete fuel pump hanger assembly designed to replace both right-hand and left-hand fuel hat assemblies in BMW E36 models. This precision-engineered hanger supports single or dual aftermarket fuel pump configurations while maintaining the factory saddle tank crossover system functionality.

Key Features:

• Compatible with 1 or 2 aftermarket fuel pumps (brushed or brushless)
• Reuses both passive and active side factory fuel level sensors
• Integrated collector bowl with fuel starvation protection for aggressive driving
• Venturi jet pump system constantly fills collector from both tank sides
• 10AN ORB (7/8"-14) female threaded fuel outlet with included SAE quick-connect barb for OEM feed line
• 10AN ORB fuel return inlet with included 8.5mm barbed adapter for OEM return line
• Stainless steel electrical studs with anti-rotation feature and hermetically sealed connections
• ETFE-insulated in-tank wiring resistant to standard and exotic fuels including E85
• No cutting or vehicle modification required for installation

This hanger features an innovative fuel starvation protection system utilizing a labyrinth-style collector bowl, return-activated venturi jet pump, and crossover scavenging to ensure consistent fuel delivery during hard cornering and acceleration. All electrical connections use serviceable stainless steel studs with non-conductive anodized aluminum acorn nuts to prevent short circuits.
