Setrab Oil Coolers 22-M22AN06-90 ProLine M22 to AN6 Oil Cooler Adapter Fitting 90 Degree

The Setrab 22-M22AN06-90 is a precision-engineered adapter fitting designed to convert Setrab ProLine oil coolers from their proprietary M22x1.5 female port to a standard AN6 (AN-06) male fitting with a 90-degree angle configuration. This adapter enables seamless connection between ProLine oil coolers and AN6 hose ends in tight-clearance applications.

Key Features:

• M22x1.5 male threads for secure connection to Setrab Series 1, 6, and 9 ProLine oil coolers
• AN6 male flare fitting accepts standard AN6 hose ends
• 90-degree angled design for space-constrained installations
• Captured O-ring design allows full 360-degree rotation after installation for optimal hose routing
• Billet aluminum construction with black anodized finish for durability and corrosion resistance
• Internally radius-machined to optimize oil flow characteristics
• Includes O-ring seal for positive internal seal to cooler port

Sold individually, allowing flexibility to use different fitting angles or sizes on inlet and outlet ports. Two adapters are typically required per oil cooler. Compatible with Setrab ProLine Series 1, 6, 9, and SLM slimline oil coolers equipped with M22 ports.
