Firestone 2912 Air Command Dual Path Analog Extreme Duty Compressor System

The Firestone 2912 Air Command Dual Analog Extreme is a professional-grade onboard air compressor system featuring an extreme duty compressor rated for 150 PSI maximum air pressure with a 100% duty cycle and 0.94 CFM output. This complete kit is designed to provide inflation control of your air helper springs, allowing you to adjust air suspension pressure on-demand for optimal ride quality and load-carrying capability.

Dual Path Control System:

The dual point fill system allows both air springs to be filled and adjusted independently of each other, ensuring balanced air pressure on each side and improving stability and control. The pneumatic analog gauge and two toggle switches come with housing for easy installation, providing real-time pressure readouts and simple left/right side control.

Complete System Includes:

• 2-gallon capacity air tank with 2 - 1/4" NPT ports and 1 - 1/8" port, measuring 8.0" height by 14.50" length
• Extreme duty compressor with 150 PSI max air pressure, 100% duty cycle, 0.94 CFM
• No-drill mounting bracket for the compressor
• Plug and play wiring harness
• 30 feet of 1/4" air tubing
• All required hardware for installation
• Dual analog gauge controller with backlit display in black plastic housing

Performance Specifications:

• Operating range: 5-150 PSI maximum pressure
• 23 AMP maximum draw
• 7-second fill rate from 0-30 PSI
• 0.94 CFM at 100 PSI
• 12V DC power system

Firestone has made enhancements to their Air Command kits with the inclusion of a no-drill mounting plate for the compressor and ECU, making installation easier than ever. This system is perfect for heavy-duty applications and off-center loads, such as slide-in campers and heavy bed loads. The onboard auxiliary air source can also be used for filling tires and other accessories, making this a versatile addition to any truck, SUV, or RV with air suspension.
