ACL Bearings 7M2394HX-STD Race Series Main Bearings Standard Size with Extra Clearance

Manufacturer

Part Number

7M2394HX-STD
Black Friday Price

$122.94

Estimated ship date Thursday, December 10

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

ACL Performance Race Bearings are manufactured with a tri-layer metal construction with hardened steel backing designed to withstand high RPM conditions, high stress loads, and high temperatures. This set includes 14 bearing halves engineered for Nissan RB-series and RD-series engines.

Key Features:

  • HX Series design is 0.0005" thinner per half to provide 0.001" extra clearance for standard sized cranks
  • Large chamfer to accommodate larger crankshaft fillets
  • 3/4 groove design provides optimum oil supply to rods and maximizes load carrying capacity
  • Increased crush and tighter wall tolerance for better seating
  • Improved overlay with reduced thickness for increased fatigue strength
  • Elimination of flash plating on bearing backs improves heat transfer and maximizes grip between bearings and housing
  • Bearing material: F780 tri-metal construction

Technical Specifications:

  • Bearing Size: Standard (STD)
  • Bearing Type: Upper and Lower halves
  • Shaft size range: 2.163" to 2.164" (54.951mm to 54.975mm)
  • Tunnel size range: 2.309" to 2.309" (58.645mm to 58.658mm)
  • Vertical oil clearance: 0.0017" to 0.0037" (0.042mm to 0.095mm)
  • Wall thickness at crown: 0.071" (1.814mm)

ACL Race Series performance engine bearings are manufactured to exacting tolerances with micron tolerance machining and precision measurement systems that deliver consistent accuracy to key characteristics like wall thickness and crush, ensuring reliable fit and consistent clearances.

Products specifications

Max Overall Length

0.752" (19.12mm) w/ 2394H/HX 1.061" (26.95mm) w/ 2395H/HX Flange

Max Std Shaft Size

2.1644" (54.975mm)

Max Std Tunnel Size

2.3094" (58.658mm)

Max Wall at Crown

0.0714" (1.814mm)

Min Std Shaft Size

2.1634" (54.951mm)

Min Std Tunnel Size

2.3089" (58.645mm)

Oil Clearance

+ 0.001" Extra

Size

Standard
