Wiseco RED0103X1 RED Series Ford Small Block Forged Piston 4.010 In. Bore -12cc Dish Single

Manufacturer

Part Number

RED0103X1
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0103X1 is a single forged piston from the RED Series (Race Engineered Design) lineup, built for Ford Small Block applications. Featuring a 4.010 in. bore, 1.090 in. compression height, and a -12cc dish crown, this piston is engineered for performance racing builds from drag racing to circle track competition.

Key Features:

  • Forged 2618 Aluminum Construction — Engineered, forged, and machined in the USA for the tensile strength required in performance racing and power adder applications
  • -12cc Dish Crown — Precision-machined dish profile for dialed-in compression ratio tuning
  • 1.090 In. Compression Height — Engine-specific geometry for optimal rod/stroke compatibility
  • 4.010 In. Bore Diameter — Sized for Ford Small Block platforms
  • ArmorGlide Skirt Coating — Reduces operating friction, noise, and skirt and cylinder wear for extended service life
  • Dedicated Engine-Specific Forging — Optimized strutted design maximizes the strength-to-weight ratio
  • Horizontal Slot Oiling in Pin Bores — Maintains optimal wrist pin and small-end lubrication, critical for long service life
  • Accumulator Groove — Helps maintain consistent ring seal for improved performance and durability
  • 0.927 In. Wrist Pin Diameter — Standard RED Series Ford pin size

Sold as a single piston replacement. The Wiseco RED Series delivers the ultimate balance of performance and value for domestic V8 racing platforms, built for racers by racers at Wiseco's Mentor, Ohio manufacturing facility.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.400

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Ford

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

5.400

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.010

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.090

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-12.00

EBAY Category ID

33623

Make - Web

Ford

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Engine - Web

Small Block

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4014GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Cylinder Head

20? Inline Valve

Title

RED Series - Ford, Small Block, 4.010 in. Bore, Piston Set of 8

Title - Web

RED Series Piston Set of 8 - Ford Small Block - 4.010 in. Bore - 1.090 in. CH, -12.00 CC
