Wiseco RED0102X1 RED Series Ford Small Block Forged Piston -15cc Dish 4.010 Bore 1.165 CH

Manufacturer

Part Number

RED0102X1
Black Friday Price

$949.99

Estimated ship date Wednesday, December 02

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0102X1 is a RED Series forged piston set engineered for Ford performance engines. Featuring a 4.010 in. bore, 1.165 in. compression height, and a -15cc dish crown design, this set is purpose-built for serious street and racing builds that demand strength and reliability.

The RED™ Series name stands for Race Engineered Design™ — a philosophy that drives every aspect of these pistons' construction, from the forging process to precision CNC machining. Designed for domestic V8 platforms, these pistons deliver the ideal balance of performance and value for applications ranging from drag racing to circle track competition.

Key Features:

  • Engineered, forged, and machined in the USA from 2618 aluminum alloy for the tensile strength required in performance racing and power-adder applications
  • Dedicated engine-specific strutted forgings optimized to maximize strength-to-weight characteristics
  • ArmorGlide® skirt coating reduces operating friction and noise while minimizing skirt and cylinder wall wear
  • Horizontal slot oiling in pin bores maintains optimal wrist pin and small-end lubrication for extended service life
  • Accumulator groove helps maintain consistent ring seal under high-load conditions
  • -15cc dish crown geometry allows precise compression ratio tuning
  • 4.010 in. bore diameter with 1.165 in. compression height

The Wiseco RED0102X1 piston set is an excellent choice for Ford engine builders seeking a race-proven forged piston that delivers durability and performance without compromise.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.250

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Ford

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

5.400

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.010

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.165

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-15.00

EBAY Category ID

33623

Make - Web

Ford

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Engine - Web

Small Block

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4014GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Cylinder Head

20? Inline Valve

Title

RED Series - Ford, Small Block, 4.010 in. Bore, Piston Set of 8

Title - Web

RED Series Piston Set of 8 - Ford Small Block - 4.010 in. Bore - 1.165 in. CH, -15.00 CC
