Wiseco RED0074X3 RED Series Forged Piston Set Ford Flat Top Bore - 5cc 4.030

Manufacturer

Part Number

RED0074X3
Black Friday Price

$899.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0074X3 is a RED Series forged piston set designed for Ford engines, featuring a -5cc flat top dome, 4.030-inch bore, and 1.280-inch compression height. Built under Wiseco's Race Engineered Design (RED) philosophy, these pistons deliver the strength, durability, and precision-machined performance that serious performance and racing builds demand.

Key Features:

  • Bore: 4.030 in.
  • Compression Height: 1.280 in.
  • Dome Volume: -5cc Flat Top
  • Application: Ford V8
  • Forged from 2618 aluminum alloy for superior tensile strength in performance and power-adder applications
  • Strutted skirt forging design for maximum strength and minimal weight
  • Precision-machined features including radiused valve pockets for improved detonation resistance and airflow
  • Includes Wiseco's GFX ring set (1.2/1.2/3.0mm steel top/Napier 2nd ring configuration) — the "X3" designation confirms ring set inclusion

Wiseco's RED Series piston sets are engineered for a wide range of domestic V8 performance applications — from drag racing and circle track to street/strip builds — offering an exceptional balance of performance and value backed by over 80 years of forged piston expertise.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

4.000

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Ford

Piston Material

2618

Rod Length

6.200

Wrist Pin Outer Diameter

0.927

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.030

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.280

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Ford

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Piston Volume

-5.00

Engine - Web

Small Block

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4032GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Cylinder Head

20? Inline Valve

Title

RED Series - Ford, Small Block, 4.030 in. Bore, Piston Set of 8

Title - Web

RED Series Piston Set of 8 - Ford Small Block - 4.030 in. Bore - 1.280 in. CH, -5.00 CC
