Wiseco RED0068X05 RED Series Ford Small Block Flat Top Piston Set 4.005 in. Bore

Manufacturer

Part Number

RED0068X05
Black Friday Price

$899.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0068X05 is a RED Series forged piston set engineered for Ford Small Block engines. Featuring a -5cc flat top design with a 4.005 in. bore and 1.165 in. compression height, this set is built for performance builders and racers seeking a reliable, high-strength piston at an exceptional value.

The RED Series (Race Engineered Design™) line is Wiseco's purpose-built performance piston for domestic V8 platforms, delivering the durability and precision needed for demanding applications ranging from street performance to drag racing and circle track competition.

Key Features:

  • Forged and machined from 2618 aluminum for the tensile strength required in performance racing and power adder applications
  • -5cc flat top dome for optimized compression ratios in Ford Small Block builds
  • 4.005 in. bore with 1.165 in. compression height and 0.927 in. pin diameter
  • ArmorGlide skirt coating reduces operating friction, minimizes noise, and decreases skirt and cylinder wear
  • Engine-specific strutted forging design maximizes the strength-to-weight ratio for each application
  • Horizontal slot oiling in pin bores maintains optimal wrist pin lubrication for extended service life
  • Accumulator groove helps maintain consistent ring seal and oil control

The Wiseco RED Series delivers the ultimate balance of performance and value for Ford Small Block builds, making it the go-to choice for engine builders who demand race-proven quality without compromise.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.250

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Ford

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

5.400

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.005

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.165

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Ford

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Piston Volume

-5.00

Engine - Web

Small Block

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4007GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Title

RED Series - Ford, Small Block, 4.005 in. Bore, Piston Set of 8

Title - Web

RED Series Piston Set of 8 - Ford Small Block - 4.005 in. Bore - 1.165 in. CH, -5.00 CC

Cylinder Head

Twisted Wedge
