Wiseco RED0063X4 Forged Piston Flat Top -5cc 4.040in Bore Ford

Manufacturer

Part Number

RED0063X4
Black Friday Price

$899.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0063X4 is a high-performance forged piston designed for Ford engines, featuring a flat top design with a -5cc valve relief. With a 4.040-inch bore diameter and a 1.230-inch compression height, this piston is built to precise tolerances for reliable power output in performance and racing applications.

Wiseco pistons are manufactured from aerospace-grade forged aluminum alloy, providing superior strength-to-weight ratios compared to cast pistons. The forging process aligns the grain structure of the aluminum, resulting in increased durability under high heat and pressure conditions found in high-performance and forced-induction engines.

Key Features:

  • Bore Diameter: 4.040 inches
  • Compression Height: 1.230 inches
  • Top Design: Flat top with -5cc valve relief
  • Application: Ford performance engines
  • Construction: Forged aluminum alloy for maximum strength
  • Precision machined to exacting tolerances for optimal ring seal and performance
  • Designed for high-RPM, high-performance, and racing engine builds

Wiseco is a trusted name in the performance aftermarket, with decades of experience supplying forged pistons to professional racers and engine builders. The RED0063X4 is an ideal choice for builders seeking a dependable, race-proven forged piston for Ford engine applications.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

4.000

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Ford

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

6.250

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.040

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.230

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Ford

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Piston Volume

-5.00

Engine - Web

Small Block

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4042GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Cylinder Head

20? Inline Valve

Title

RED Series - Ford, Small Block, 4.040 in. Bore, Piston Set of 8

Title - Web

RED Series Piston Set of 8 - Ford Small Block - 4.040 in. Bore - 1.230 in. CH, -5.00 CC
