Wiseco RED0063X05 Ford Small Block RED Series -5cc Flat Top Forged Piston Set

Manufacturer

Part Number

RED0063X05
Black Friday Price

$899.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

Featuring a 4.005 in. bore, 1.230 in. compression height, and a -5cc flat top crown, these pistons are precision-matched for high-performance and race applications where exact deck clearance and compression ratio control are critical.

Key Specifications:

  • Bore Diameter: 4.005 in.
  • Compression Height: 1.230 in.
  • Crown Volume: -5cc (Flat Top)
  • Wrist Pin Diameter: 0.927 in.
  • Set Quantity: 8 pistons
  • Application: Ford Small Block

RED Series Features:

  • Forged construction using high-strength 2618 aluminum alloy for superior thermal and mechanical durability
  • Race Engineered Design™ (RED™) strutted forging process for optimized strength-to-weight ratio
  • Precision-machined ring grooves for consistent ring seal under high-boost and high-RPM conditions
  • ArmorGlide™ skirt coating for reduced friction, seizure resistance, and quieter operation
  • CNC-machined crown features for accurate compression ratio targeting
  • Engineered, forged, and machined in the USA at Wiseco's Mentor, Ohio facility

The RED0063X05 piston set delivers the strength and precision demanded by serious performance builders — from bracket racing to circle track — while offering outstanding value in a forged piston platform. Includes 8 pistons and matching piston rings.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

4.000

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Ford

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

6.250

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.005

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.230

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Ford

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Piston Volume

-5.00

Engine - Web

Small Block

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4007GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Cylinder Head

20? Inline Valve

Title

RED Series - Ford, Small Block, 4.005 in. Bore, Piston Set of 8

Title - Web

RED Series Piston Set of 8 - Ford Small Block - 4.005 in. Bore - 1.230 in. CH, -5.00 CC
