Carrillo MX3023C Platinum Series Piston KX250F 77mm 14.2:1 Compression

Manufacturer

Part Number

MX3023C
Sale Price

$325.12

Estimated ship date Sunday, November 29

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The CP-Carrillo MX3023C is a Platinum Series high-performance forged piston engineered for the 2004–2009 Kawasaki KX250F. Designed to work in conjunction with the Carrillo Platinum Long Rod on a stock stroke crankshaft, this piston is purpose-built for serious motocross and off-road competition, delivering measurable power gains over the factory piston.

Key Specifications:

  • Bore: 77mm (standard bore)
  • Stroke: 53.6mm
  • Displacement: 249cc
  • Compression Ratio: 14.2:1
  • Wrist Pin: 1mm smaller diameter (Platinum Long Rod compatible)
  • Rod Compatibility: Requires Carrillo Platinum Long Rod (1.5mm longer than stock)

CP-Carrillo Project X Technology:

  • Advanced forged construction using CP-Carrillo's proprietary Project X process
  • Profiled pin bore reduces stress concentration in the pin bore area — one of the most highly loaded regions of the piston
  • Engineered to allow the wrist pin to flex naturally, dramatically improving durability under sustained high-RPM racing loads
  • Wider and deeper valve reliefs to accommodate larger valves and high-lift camshafts
  • Coated side skirts for reduced friction and improved scuff resistance
  • Double pin oilers for superior lubrication at the wrist pin

The Platinum Series long-rod geometry reduces piston side-load against the cylinder wall, allowing the piston to spend more time at top dead center for a more complete combustion event. This design — once exclusive to factory race teams — is now available for the competition rider seeking a genuine performance edge. The MX3023C piston is sold individually and is intended for use as part of the Carrillo Platinum Kit for the KX250F.
