Wiseco RED0096X6 RED Series Chevrolet Big Block Piston Set 4.560 in. Bore 10cc Dome

Manufacturer

Part Number

RED0096X6
Black Friday Price

$999.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0096X6 is a RED Series forged piston set for Chevrolet Big Block engines, featuring a 4.560 in. bore, 1.270 in. compression height, and a +10cc dome crown.

Key Features:

  • Race Engineered Design (RED): Engineered, forged, and machined in the USA from 2618 aluminum alloy for the tensile strength needed in performance racing and power adder applications
  • Strutted Forging: Dedicated, engine-specific strutted design maximizes the strength-to-weight ratio
  • ArmorGlide® Skirt Coating: Reduces operating friction and noise while minimizing skirt and cylinder wear for extended service life
  • Horizontal Slot Pin Bore Oiling: Maintains optimal wrist pin and connecting rod small-end lubrication, critical for durability under high loads
  • 10cc Dome Crown: Positive dome design increases compression ratio for maximum power output

Specifications:

  • Bore: 4.560 in.
  • Compression Height: 1.270 in.
  • Pin Diameter: 0.990 in.
  • Dome Volume: +10cc
  • Application: Chevrolet Big Block

The Wiseco RED Series delivers race-proven performance for domestic V8 platforms, making it a top choice for drag racing, circle track, and high-output street/strip builds.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Rod Length

6.385

Second Ring Material

Iron

Stroke

4.250

Top Ring Material

Ductile iron

Wrist Pin Retainer Material

Carbon steel

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.560

Oil Ring Thickness

0.1875

Third Ring Material

Carbon Steel

Compression Height

1.270

Industry

Automotive

Product Market

Domestic

Top Compression Ring Thickness

0.0625

Engine Type

ICE

Engine

Big Block

Wrist Pin Material

5115

Product Type

Engine Piston Set

Wrist Pin Outer Diameter

0.990

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

10.00

EBAY Category ID

33623

Engine - Web

Big Block

Make - Web

Chevrolet

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Product Series

RED Series

Cylinder Head

Conventional Open Chamber

Second Compression Ring Thickness

0.0625

Wrist Pin Part Number

S460

Wrist Pin Quantity

8

Wrist Pin Retainer Part Number

CS25

Wrist Pin Retainer Thickness

0.084

Ring Quantity

8

Wrist Pin Retainer Quantity

32

Wrist Pin Retainer Style

Spiro Lock

Title

RED Series - Chevrolet, Big Block, 4.560 in. Bore, Piston Set of 8

Title - Web

RED Series Piston Set of 8 - Chevrolet Big Block - 4.560 in. Bore - 1.270 in. CH, 10.00 CC

Ring Set Part Number

J10001-4560-5
