Wiseco RED0096X100 RED Series Chevrolet Big Block Forged Piston 10cc Dome 4.600 in. Bore

Manufacturer

Part Number

RED0096X100
Black Friday Price

$999.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0096X100 is a RED Series forged piston engineered for Chevrolet Big Block applications, featuring a 4.600 in. bore (+0.100 in. oversize), 1.270 in. compression height, and a 10cc dome profile. Forged from 2618 aluminum alloy, this piston delivers the tensile strength required for performance racing, power adder, and high-output street engine builds.

Key Features:

  • Race Engineered Design (RED): Precision-machined forging optimized for domestic V8 performance and racing applications
  • 2618 Aluminum Alloy Construction: Engineered, forged, and machined in the USA for superior tensile strength under high heat and pressure
  • ArmorGlide® Skirt Coating: Reduces operating friction and noise while minimizing skirt and cylinder wall wear for extended service life
  • Strutted Forging Design: Dedicated engine-specific forging maximizes strength-to-weight ratio
  • Horizontal Slot Pin Bore Oiling: Maintains optimal wrist pin lubrication critical for longevity in demanding applications
  • Precision Ring Grooves: Fully machined crown and ring groove features for consistent sealing and performance
  • Bore Size: 4.600 in. (+0.100 in. oversize)
  • Compression Height: 1.270 in.
  • Pin Diameter: 0.990 in.
  • Dome Volume: 10cc dome

The Wiseco RED Series is purpose-built for popular domestic V8 platforms, covering everything from drag racing to circle track competition. Manufactured at Wiseco's Mentor, Ohio facility, these pistons represent an outstanding combination of race-bred engineering and competitive value.

Products specifications

Oil Ring Tension

Ultra low

Piston Quantity

8

Rod Length

6.385

Second Ring Material

Iron

Stroke

4.250

Top Ring Material

Ductile iron

Wrist Pin Retainer Material

Carbon steel

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.600

Oil Ring Thickness

0.1875

Third Ring Material

Carbon Steel

Compression Height

1.270

Industry

Automotive

Product Market

Domestic

Top Compression Ring Thickness

0.0625

Engine Type

ICE

Engine

Big Block

Wrist Pin Material

5115

Product Type

Engine Piston Set

Wrist Pin Outer Diameter

0.990

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

10.00

EBAY Category ID

33623

Engine - Web

Big Block

Make - Web

Chevrolet

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Product Series

RED Series

Cylinder Head

Conventional Open Chamber

Second Compression Ring Thickness

0.0625

Wrist Pin Part Number

S460

Wrist Pin Quantity

8

Wrist Pin Retainer Part Number

CS25

Wrist Pin Retainer Thickness

0.084

Ring Quantity

8

Wrist Pin Retainer Quantity

32

Wrist Pin Retainer Style

Spiro Lock

Title

RED Series - Chevrolet, Big Block, 4.600 in. Bore, Piston Set of 8

Title - Web

RED Series Piston Set of 8 - Chevrolet Big Block - 4.600 in. Bore - 1.270 in. CH, 10.00 CC

Ring Set Part Number

J100U1-4600-5
