Wiseco RED0049XS RED Series Chevy Small Block Piston Dish CH Bore - 400/421 9cc 1.062 4.120

Manufacturer

Part Number

RED0049XS
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0049XS is a RED Series forged piston designed for the Chevrolet Small Block 400/421 stroker platform. Featuring a 4.120-inch bore diameter, 1.062-inch compression height, and a -9cc dish top, this piston is precision-engineered for performance builds ranging from street/strip to circle track applications.

Key Features:

  • Race Engineered Design (RED™) — purpose-built for strength and durability in high-performance and power-adder environments
  • 2618 aluminum alloy — forged and machined in the USA for superior tensile strength under extreme heat and cylinder pressure
  • -9cc dish top — allows fine-tuning of compression ratio to suit a variety of SBC 400/421 stroker combinations
  • 1.062-inch compression height — engineered specifically for the 400/421 small block stroker geometry
  • ArmorGlide® skirt coating — reduces operating friction and wear on both the skirt and cylinder wall, improving longevity and reducing noise
  • Dedicated engine-specific forging — strutted design optimizes the strength-to-weight ratio for this application
  • Horizontal slot oiling in pin bores — maintains consistent wrist pin lubrication for extended service life
  • 0.927-inch pin diameter — standard RED Series wrist pin sizing

Sold as an individual piston, the RED0049XS is ideal for engine builders assembling or rebuilding a Chevy Small Block 400 or 421 cubic inch stroker combination. Wiseco RED Series piston kits are available separately for full 8-cylinder sets.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.875

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

6.000

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.125

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.062

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-9.00

EBAY Category ID

33623

Make - Web

Chevrolet

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Engine - Web

Small Block

Title

RED Series - Chevrolet, Small Block, 4.125 in. Bore, Piston Set of 8

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4127GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Cylinder Head

Small Block 23?

Title - Web

RED Series Piston Set of 8 - Chevrolet Small Block - 4.125 in. Bore - 1.062 in. CH, -9.00 CC
