Wiseco RED0047XS RED Series Chevy Small Block 400 Piston Set 4.120 In. Bore 1.250 In. CH -1cc Dome

Manufacturer

Part Number

RED0047XS
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0047XS is a RED Series forged piston set engineered for the Chevrolet Small Block 400 platform. Featuring a 4.120-inch bore, 1.250-inch compression height, and a -1cc dome profile, this set is purpose-built to deliver the strength and precision demanded by serious performance and racing applications.

Key Features:

  • Race Engineered Design (RED™): Forged, engineered, and machined in the USA from 2618 aluminum for the tensile strength required in performance racing and power adder applications
  • Dedicated Strutted Forgings: Engine-specific strutted design optimizes the strength-to-weight ratio for this application
  • ArmorGlide® Skirt Coating: Reduces operating friction and noise while minimizing skirt and cylinder wall wear
  • Horizontal Slot Pin Bore Oiling: Maintains optimal wrist pin and small-end lubrication for long service life
  • Accumulator Groove: Helps maintain consistent ring seal and power output
  • Premium Rings Included: Each part number ships with premium rings — no additional sourcing required

Specifications:

  • Bore: 4.120 in.
  • Compression Height: 1.250 in.
  • Dome Volume: -1cc
  • Pin Diameter: 0.927 in.
  • Ring Grooves: 1/16 in. – 1/16 in. – 3/16 in.
  • Cross-Reference: KE179M835

The Wiseco RED Series delivers the ultimate balance of performance and value for domestic V8 builds, from drag racing to circle track competition.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.480

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

6.000

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.125

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.250

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Chevrolet

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Engine - Web

Small Block

Piston Volume

-1.00

Title

RED Series - Chevrolet, Small Block, 4.125 in. Bore, Piston Set of 8

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4127GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Cylinder Head

Small Block 23?

Title - Web

RED Series Piston Set of 8 - Chevrolet Small Block - 4.125 in. Bore - 1.250 in. CH, -1.00 CC
