Wiseco RED0047X4 Chevy Small Block 400/372 Forged Piston Set -1cc Dome 4.160 in. Bore 1.250 in. CH

Manufacturer

Part Number

RED0047X4
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

Featuring a 4.160-inch bore, 1.250-inch compression height, and a -1cc dome volume, this piston set is precision-engineered for performance racing and high-output builds.

Key Features:

  • Race Engineered Design (RED™ Series): Forged and CNC-machined in the USA from 2618 aluminum alloy for the tensile strength demanded by performance racing and power adder applications
  • Bore: 4.160 in.
  • Compression Height: 1.250 in.
  • Pin Diameter: 0.927 in.
  • Dome Volume: -1cc (dome)
  • Dedicated Engine-Specific Forging: Optimized strutted design maximizes strength-to-weight ratio for the SBC 400/372 platform
  • ArmorGlide® Skirt Coating: Reduces operating friction and noise while minimizing skirt and cylinder wall wear for extended service life
  • Horizontal Slot Oiling: Pin bore oiling slots maintain optimal wrist pin and small-end rod lubrication — critical under high-RPM racing conditions

The RED™ Series piston sets are built for serious engine builders and racers competing in drag racing, circle track, and other high-demand motorsports disciplines. Engineered, forged, and machined entirely in the USA, the RED0047X4 delivers the durability and precision needed for competitive performance on the Chevrolet Small Block 400 and 372 platforms.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.480

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

6.000

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.165

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.250

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Chevrolet

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Engine - Web

Small Block

Piston Volume

-1.00

Title

RED Series - Chevrolet, Small Block, 4.165 in. Bore, Piston Set of 8

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Ring Set Part Number

4168GFX

Wrist Pin Retainer Thickness

0.072

Cylinder Head

Small Block 23?

Title - Web

RED Series Piston Set of 8 - Chevrolet Small Block - 4.165 in. Bore - 1.250 in. CH, -1.00 CC
