Wiseco RED0047X3 RED Series Chevy Small Block 400 Forged Piston Set 4.150 In. Bore 1.250 In. CH -1cc Dome

Manufacturer

Part Number

RED0047X3
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

With a 4.150 in. bore diameter, 1.250 in. compression height, and a -1cc dome volume, this kit is engineered to deliver the strength, precision, and durability demanded by serious performance builds — from circle track to drag racing.

Key Features:

  • Forged 2618 aluminum construction — engineered, forged, and machined in the USA for the tensile strength required in high-performance and power-adder applications
  • Dedicated strutted forgings — engine-specific design optimizes the strength-to-weight ratio for this application
  • ArmorGlide® skirt coating — dry film lubricant permanently bonded to the skirt reduces operating friction, minimizes cylinder and skirt wear, and quiets piston operation
  • Horizontal slot oiling in pin bores — maintains optimal wrist pin and small-end lubrication for extended service life
  • Accumulator groove — helps maintain consistent ring seal and sustained power output
  • Premium ring set included — no additional ring sourcing required
  • -1cc dome profile — slight dome design aids compression tuning for the Chevrolet 400/372 small block platform

Specifications:

  • Bore: 4.150 in.
  • Compression Height: 1.250 in.
  • Dome Volume: -1cc
  • Wrist Pin Diameter: 0.927 in.
  • Material: 2618 forged aluminum
  • Series: RED™ (Race Engineered Design™)
  • MPN: RED0047X3

Wiseco RED™ Series piston kits represent the ultimate balance of performance and value for domestic V8 applications. Built and machined in the USA at Wiseco's facility in Mentor, Ohio, these pistons are trusted by engine builders across all forms of racing and high-performance street use.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.480

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

6.000

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.155

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.250

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Chevrolet

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Engine - Web

Small Block

Piston Volume

-1.00

Title

RED Series - Chevrolet, Small Block, 4.155 in. Bore, Piston Set of 8

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Ring Set Part Number

4158GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Wrist Pin Retainer Thickness

0.072

Cylinder Head

Small Block 23?

Title - Web

RED Series Piston Set of 8 - Chevrolet Small Block - 4.155 in. Bore - 1.250 in. CH, -1.00 CC
