Wiseco RED0009XS RED Series Chevy Small Block Forged Piston Set Dish Bore - 350/383 17cc 4.000

Manufacturer

Part Number

RED0009XS
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0009XS is a RED Series forged piston set designed for the Chevrolet Small Block 350/383 engine platform.

The RED (Race Engineered Design) series represents Wiseco's mid-level performance piston line, engineered for enthusiasts pursuing moderate power upgrades including power adder applications such as forced induction and nitrous. Each piston is forged, engineered, and precision-machined in the USA from 2618 aluminum alloy, providing superior tensile strength and heat dissipation compared to standard 4032 alloy pistons.

Key Features:

  • 2618 aluminum alloy construction — superior tensile strength and heat dissipation for performance racing and power adder applications
  • Dedicated engine-specific forgings — optimized strutted design maximizes strength-to-weight characteristics
  • ArmorGlide® skirt coating — reduces operating friction, noise, skirt wear, and cylinder wall wear
  • Horizontal slot pin bore oiling — maintains optimal wrist pin and small-end lubrication for long service life
  • Accumulator groove — helps maintain consistent ring seal and power output
  • GFX Ring Pack included — premium ring technology with superior sealing and reduced friction; no additional sourcing required
  • -17cc dish crown — engineered for efficient combustion and proper compression ratio with common 350/383 combinations

Wiseco RED Series piston kits are purpose-built for popular domestic V8 platforms, from drag racing to circle track competition. The RED0009XS is manufactured at Wiseco's facility in the USA and is an excellent choice for high-performance 350 or 383 stroker builds requiring a reliable, race-proven forged piston at a competitive price point.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.750

Top Ring Material

Steel

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.000

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.425

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-17.00

EBAY Category ID

33623

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Rod Length

5.700

Engine

Small Block 350

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Make - Web

Chevy

Ring Set Part Number

4000GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Cylinder Head

23 Degree

Title

RED Series - Chevrolet, Small Block 350, 4.000 in. Bore, Piston Set of 8

Wrist Pin Retainer Material

Chrome Silicone

Engine - Web

Small Block 350

Wrist Pin Retainer Thickness

0.0720

Title - Web

RED Series Chevy Small Block 350 Piston Set of 8 - 4.000 in. Bore - 1.425 in. CH, -17.00 CC
