Wiseco RED0009X6 RED Series Chevy Small Block 350/383 Forged Piston Set -17cc Dish 4.060 in. Bore

Manufacturer

Part Number

RED0009X6
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

Featuring a 4.060 in. bore, 1.425 in. compression height, 0.927 in. pin diameter, and a -17.00cc dish crown, this piston set delivers the precise dimensions and strength required for serious performance and power adder builds.

Key Features:

  • 2618 forged aluminum construction — engineered, forged, and machined in the USA for the tensile strength demanded by racing and power adder applications
  • Engine-specific strutted forging — dedicated forgings allow for an optimized design that maximizes strength-to-weight characteristics
  • ArmorGlide® skirt coating — reduces operating friction and noise while minimizing skirt and cylinder wear for longer service life
  • Horizontal slot oiling in pin bores — maintains optimal wrist pin and small-end lubrication, critical for durability under sustained high-RPM operation
  • Accumulator groove — helps maintain consistent ring seal and power output
  • Premium rings included — no need for additional sourcing; everything needed is in the box
  • -17.00cc dish crown — allows tuning of compression ratio for a wide range of 350/383 small block builds

The Wiseco RED Series is the ideal choice for domestic V8 performance builds ranging from drag racing to circle track competition, offering an outstanding balance of race-proven performance and value.

Specifications:

  • Bore: 4.060 in.
  • Compression Height: 1.425 in.
  • Pin Diameter: 0.927 in.
  • Combustion Chamber Volume: -17.00cc (Dish)
  • Material: 2618 Forged Aluminum
  • Series: RED Series (Race Engineered Design™)

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.750

Top Ring Material

Steel

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.060

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.425

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-17.00

EBAY Category ID

33623

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Rod Length

5.700

Engine

Small Block 350

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Make - Web

Chevy

Ring Set Part Number

4062GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Cylinder Head

23 Degree

Title

RED Series - Chevrolet, Small Block 350, 4.060 in. Bore, Piston Set of 8

Wrist Pin Retainer Material

Chrome Silicone

Engine - Web

Small Block 350

Wrist Pin Retainer Thickness

0.0720

Title - Web

RED Series Chevy Small Block 350 Piston Set of 8 - 4.060 in. Bore - 1.425 in. CH, -17.00 CC
