Wiseco RED0009X3 RED Series Chevy Small Block Piston Set Dish Bore - 350/383 17cc 4.030

Manufacturer

Part Number

RED0009X3
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0009X3 is a RED Series forged piston set designed for Chevrolet Small Block 350 and 383 engines.

Race Engineered Design (RED) Series Technology:

  • 2618 forged aluminum construction — engineered, forged, and machined in the USA for the tensile strength required in performance racing and power-adder applications
  • -17cc dish crown — lowers compression ratio for use with forced induction, nitrous, or high-compression street builds
  • 1.425 in. compression height with 0.927 in. wrist pin diameter
  • 4.030 in. bore diameter — fits standard overbore Chevy 350/383 small block applications
  • ArmorGlide® skirt coating — reduces operating friction and noise while minimizing skirt and cylinder wall wear
  • Dedicated engine-specific forging — optimized strutted design maximizes strength-to-weight characteristics
  • Horizontal slot oiling in pin bores — maintains optimal wrist pin and small-end lubrication for long service life

Wiseco's RED Series pistons represent the ultimate balance of performance and value for popular domestic V8 platforms. Built to withstand the demands of power adders and high-performance builds, the RED0009X3 is a proven choice for serious Chevy small block engine builders.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.750

Top Ring Material

Steel

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.030

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.425

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-17.00

EBAY Category ID

33623

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Rod Length

5.700

Engine

Small Block 350

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Make - Web

Chevy

Ring Set Part Number

4032GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Cylinder Head

23 Degree

Title

RED Series - Chevrolet, Small Block 350, 4.030 in. Bore, Piston Set of 8

Wrist Pin Retainer Material

Chrome Silicone

Engine - Web

Small Block 350

Wrist Pin Retainer Thickness

0.0720

Title - Web

RED Series Chevy Small Block 350 Piston Set of 8 - 4.030 in. Bore - 1.425 in. CH, -17.00 CC
