Wiseco RED0009X2 RED Series Chevy 350/383 Piston Set -17cc Dish 1.425 CH 4.000 Bore

Manufacturer

Part Number

RED0009X2
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0009X2 is a complete 8-piece forged piston set from Wiseco's RED™ Series (Race Engineered Design™), purpose-built for Chevrolet Small Block 350 and 383 engines. This set features a 4.000 in. bore, 1.425 in. compression height, -17cc dish combustion chamber volume, and a 0.927 in. wrist pin diameter — making it an ideal choice for performance street and racing applications.

Key Features:

  • 2618 aluminum alloy construction — engineered, forged, and machined in the USA for the tensile strength required in high-performance and power-adder applications
  • Dedicated engine-specific forgings — optimized strutted skirt design maximizes strength-to-weight characteristics for the SBC 350/383 platform
  • ArmorGlide® skirt coating — reduces operating friction and noise while minimizing skirt and cylinder wall wear
  • Horizontal slot oiling in pin bores — maintains optimal wrist pin and small-end rod lubrication for long service life
  • Accumulator groove — helps maintain consistent ring seal and power output
  • Premium ring set included — complete package with no need for additional ring sourcing
  • -17cc dish top — supports flexible compression ratio tuning across a range of stroke and head combinations

The RED™ Series is designed for popular domestic V8 platforms and covers applications from drag racing to circle track. Rings included.

Specifications:

  • Bore: 4.000 in.
  • Compression Height: 1.425 in.
  • Dish Volume: -17cc
  • Pin Diameter: 0.927 in.
  • Material: 2618 Forged Aluminum

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.750

Top Ring Material

Steel

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.020

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.425

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-17.00

EBAY Category ID

33623

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Rod Length

5.700

Engine

Small Block 350

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Make - Web

Chevy

Ring Set Part Number

4022GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Cylinder Head

23 Degree

Title

RED Series - Chevrolet, Small Block 350, 4.020 in. Bore, Piston Set of 8

Wrist Pin Retainer Material

Chrome Silicone

Engine - Web

Small Block 350

Wrist Pin Retainer Thickness

0.0720

Title - Web

RED Series Chevy Small Block 350 Piston Set of 8 - 4.020 in. Bore - 1.425 in. CH, -17.00 CC
