Wiseco RED0009X1 RED Series Chevy Small Block Forged Piston Set Dish Bore CH - 350/383 17cc 4.000 1.425

Manufacturer

Part Number

RED0009X1
Black Friday Price

$949.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0009X1 is a complete 8-piece forged piston set engineered for the Chevrolet Small Block 350 and 383 stroker engine platforms. Featuring a -17cc dish crown, 4.000 in. bore, and 1.425 in. compression height, this set is precision-built for performance and power-adder applications.

Part of Wiseco's RED™ Series — short for Race Engineered Design™ — these pistons are manufactured and machined entirely in the USA from 2618 aluminum alloy, delivering the tensile strength required for high-horsepower builds including forced induction and nitrous applications.

Key Features:

  • Bore: 4.000 in.
  • Compression Height: 1.425 in.
  • Pin Diameter: 0.927 in.
  • Crown Volume: -17cc Dish
  • Material: 2618 high-strength forged aluminum alloy
  • ArmorGlide® skirt coating reduces operating friction and minimizes skirt and cylinder wear
  • GFX Ring Pack provides superior sealing, reduced friction, and increased ring longevity
  • Horizontal slot pin oiling ensures consistent lubrication under high-load racing conditions
  • Dedicated engine-specific strutted forging optimizes strength-to-weight ratio
  • Rated for over 1,000 horsepower
  • Engineered, forged, and machined in the USA

The RED™ Series is purpose-built for domestic V8 racing platforms, making it a top choice for drag racing, circle track, and street/strip builds. The -17cc dish design allows builders to tune compression ratio to suit a wide range of cylinder head and gasket combinations.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

8

Second Ring Material

Ductile iron

Stroke

3.750

Top Ring Material

Steel

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.010

Oil Ring Thickness

3.00

Third Ring Material

Stainless Steel

Compression Height

1.425

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-17.00

EBAY Category ID

33623

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Rod Length

5.700

Engine

Small Block 350

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Ring Quantity

8

Make - Web

Chevy

Ring Set Part Number

4007GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Cylinder Head

23 Degree

Title

RED Series - Chevrolet, Small Block 350, 4.010 in. Bore, Piston Set of 8

Wrist Pin Retainer Material

Chrome Silicone

Engine - Web

Small Block 350

Wrist Pin Retainer Thickness

0.0720

Title - Web

RED Series Chevy Small Block 350 Piston Set of 8 - 4.010 in. Bore - 1.425 in. CH, -17.00 CC
