Wiseco K682M87 Professional Forged Piston Set Honda F20C F22C 87mm 7cc Dome

Manufacturer

Part Number

K682M87
Black Friday Price

$681.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

Featuring an 87mm (3.425 in.) bore, a 1.141 in. compression height, a 0.905 in. pin diameter, and a +7cc dome crown, this set is purpose-built for high-compression, heavy-duty race builds where stock pistons simply cannot keep up.

Key Features:

  • 87mm Bore / 3.425 in. — Standard bore size for F22C sleeved applications
  • 1.141 in. Compression Height — Precisely engineered for proper deck clearance
  • 0.905 in. Pin Diameter — Matched to premium 4130 chrome moly wrist pins included in kit
  • +7cc Dome Crown — Raises static compression ratio for naturally aspirated performance
  • 2618 Forged Aluminum Construction — Engineered, forged, and machined in the USA for superior tensile strength and impact resistance
  • ArmorGlide® Skirt Coating — Dry-film lubricant permanently bonded to skirt for reduced friction, quieter operation, and seizure resistance
  • ArmorPlating Coating — Applied to piston crown, ring grooves, and pin bore; raises hardness, prevents micro-welding of rings, reduces carbon buildup, and combats detonation-induced corrosion
  • Valve Pockets — Designed for maximum flow clearance, compatible with oversized valves and high-lift camshafts
  • Gas Nitrided Piston Ring Set Included — Complete kit includes premium rings, 4130 chrome moly wrist pins, and locks

Important Notes: The Honda F20C/F22C uses FRM (Fiber Reinforced Metal) cylinder liners from the factory. Aftermarket cylinder sleeves are required when using these pistons. This set is designed for forced induction, nitrous, and naturally aspirated race applications.

Wiseco's Professional Series represents the pinnacle of their piston technology — packed with custom-level performance and durability features designed and built for heavy to severe duty race builds. Each piston is engineered and machined at Wiseco's Mentor, Ohio manufacturing facility.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

4

Second Ring Material

Ductile iron

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Piston Material

2618

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Oil Ring Thickness

2.80

Make

Honda

Third Ring Material

Stainless Steel

Compression Height

1.141

Industry

Automotive

Product Market

Sport Compact

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.00

Engine Type

ICE

Wrist Pin Material

5115

Product Series

Professional

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Honda

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Piston Volume

7.00

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Wrist Pin Retainer Thickness

0.049

Bore Diameter

3.425

Ring Set Part Number

8700XX

Wrist Pin Outer Diameter

0.905

Wrist Pin Quantity

4

Wrist Pin Retainer Quantity

8

Cylinder Head

F22C

Engine

F22C

Rod Length

6.023

Stroke

3.307

Title

Professional - Honda, F22C, 3.425 in. Bore, Piston Set of 4

Ring Quantity

4

Engine - Web

F22C

Title - Web

Professional Piston Set of 4 Honda F22C - 3.425 in. Bore - 1.141 in. CH, 7.00 CC

Wrist Pin Part Number

S551

Wrist Pin Retainer Part Number

CW23
