Wiseco K553M855 Forged Piston Kit Mazda Turbo 85.5mm Bore -4cc Dish

Manufacturer

Part Number

K553M855
Black Friday Price

$752.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco K553M855 is a high-performance forged piston kit designed for Mazda turbocharged engine applications. Built to Wiseco's exacting standards, this kit features an 85.5mm bore diameter and a -4cc dish volume, making it ideal for performance builds that demand reliable power under boost.

Key Features:

  • Bore Diameter: 85.5mm (M855) for precise fitment in Mazda turbo applications
  • Dish Volume: -4cc for optimized compression ratio tuning in forced-induction setups
  • Compression Height: 1.201 inches for accurate deck clearance and rod/stroke compatibility
  • Forged Construction: Wiseco's aerospace-grade forged aluminum alloy for superior strength-to-weight ratio
  • Performance Coatings: Includes Wiseco's ArmorGlide skirt coating to reduce friction and improve ring seal
  • Ring Grooves: Precision-machined ring grooves for consistent ring seal and longevity under high-boost conditions
  • Complete Kit: Includes forged pistons with wrist pins, retaining clips, and piston rings

Wiseco forged pistons are a trusted choice among professional engine builders and performance enthusiasts. The K553M855 is engineered to withstand the elevated cylinder pressures and temperatures associated with turbocharged and supercharged applications, providing a reliable foundation for high-output Mazda engine builds.

Products specifications

Oil Ring Tension

Standard

Piston Quantity

4

Second Ring Material

Ductile iron

Top Ring Material

Stainless steel

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Mazda

Piston Material

2618

Stroke

5.236

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Oil Ring Thickness

2.80

Third Ring Material

Stainless Steel

Compression Height

1.201

Industry

Automotive

Product Market

Sport Compact

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.00

Engine Type

ICE

Wrist Pin Material

5115

Product Series

Professional

Product Type

Engine Piston Set

Wrist Pin Outer Diameter

0.787

Forging Type

Full Round

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Make - Web

Mazda

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Wrist Pin Retainer Thickness

0.049

Engine

BP

Engine - Web

BP

Bore Diameter

3.366

Ring Set Part Number

8550XX

Piston Volume

-4.20

Wrist Pin Quantity

4

Wrist Pin Retainer Quantity

8

Cylinder Head

BP

Rod Length

3.346

Title

Professional - Mazda, BP, 3.366 in. Bore, Piston Set of 4

Ring Quantity

4

Title - Web

Professional Piston Set of 4 Mazda BP - 3.366 in. Bore - 1.201 in. CH, -4.20 CC

Wrist Pin Part Number

S623

Wrist Pin Retainer Part Number

CW20
