Wiseco K0248X3 Ford Pinto Professional Series Forged Piston Set Bore - 2300 3.810

Manufacturer

Part Number

K0248X3
Black Friday Price

$506.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco K0248X3 is a Professional Series forged piston set designed for the Ford 2.3L 2300/Pinto 4-cylinder engine. Built for serious racers and engine builders, this set delivers custom-level performance and durability engineered to handle heavy to severe duty race applications.

Key Specifications:

  • Bore: 3.810 in.
  • Compression Height: 1.090 in.
  • Pin Diameter: 0.866 in.
  • Combustion Volume: -3.4cc (dish)
  • Stroke: 3.126 in.
  • Rod Length: 5.700 in.
  • Top Land: 0.200 in.
  • Skirt Type: Strutted
  • Ring Grooves: 1.5mm / 1.5mm / 3.0mm (rings sold separately)
  • Set Includes: 4 pistons

Key Features:

  • 2618 Forged Aluminum Construction — engineered and machined in the USA for improved tensile strength and superior heat resistance
  • ArmorGlide® Skirt Coating — reduces friction, resists seizure, and promotes quieter operation
  • Lateral Gas Ports — improves ring seal and combustion efficiency under race conditions
  • Anti-Detonation & Pressure Seal Grooves — enhances durability and sealing performance
  • Mini-Stock Race Design — purpose-built for 2300/Pinto mini-stock, road race, and circle track applications

Compression ratio at 0 deck with 0.040 in. head gasket varies by combustion chamber volume: approximately 11.4:1 at 42cc, 10.7:1 at 46cc, 10.1:1 at 50cc, and 9.6:1 at 54cc. Ringset sold separately; consult Wiseco for the correct ring part number for this bore size.

Products specifications

Piston Quantity

4

Stroke

3.126

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Ford

Piston Material

4032

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

3.810

Oil Ring Thickness

3.00

Compression Height

1.090

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.50

Top Compression Ring Thickness

1.50

Engine Type

ICE

Wrist Pin Material

5115

Product Series

Professional

Product Type

Engine Piston Set

Wrist Pin Outer Diameter

0.866

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-3.40

EBAY Category ID

33623

Make - Web

Ford

Ring Set Included

No

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Rod Length

5.700

Wrist Pin Retainer Part Number

W5590

Wrist Pin Retainer Thickness

0.063

Wrist Pin Quantity

4

Wrist Pin Retainer Quantity

8

Wrist Pin Part Number

S655

Cylinder Head

Lima

Engine

Lima

Title

Professional - Ford, Lima, 3.810 in. Bore, Piston Set of 4

Engine - Web

Lima

Title - Web

Professional Piston Set of 4 Ford Lima - 3.810 in. Bore - 1.090 in. CH, -3.40 CC
