Wiseco K0247X5 Ford Lima 2300 Pinto Professional Series Forged Piston Set 3.830 Bore

Manufacturer

Part Number

K0247X5
Black Friday Price

$506.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco K0247X5 is a Professional Series forged piston set engineered for the Ford Lima 2300 (Pinto) 2.3L 4-cylinder engine. Designed for serious racers and builders, this set delivers the strength and precision required for high-performance and racing applications.

Key Specifications:

  • Bore: 3.830 in.
  • Compression Height: 1.090 in.
  • Pin Diameter: 0.927 in.
  • Dome Volume: -3.4cc (dished)
  • Application: Ford Lima 2300 / Pinto 2.3L 4-Cylinder

Features:

  • 2618 Aluminum Alloy — high-grade forging material providing superior strength and resilience under extreme heat and pressure
  • ArmorGlide® Skirt Coating — reduces operating friction to minimize skirt and cylinder wall wear, extending component life
  • Anti-detonation and pressure seal grooves for enhanced combustion sealing
  • Engineered and machined at Wiseco's Mentor, Ohio manufacturing facility using advanced CNC equipment
  • Compatible with forced induction applications including turbocharged and supercharged builds

Rings are sold separately. The Wiseco K0247X5 is ideal for road racing, circle track, and high-performance street builds demanding no-compromise piston quality.

Products specifications

Piston Quantity

4

Stroke

3.126

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Ford

Piston Material

4032

Wrist Pin Outer Diameter

0.927

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

3.830

Oil Ring Thickness

3.00

Compression Height

1.090

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.50

Top Compression Ring Thickness

1.50

Engine Type

ICE

Wrist Pin Material

5115

Product Series

Professional

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-3.40

EBAY Category ID

33623

Make - Web

Ford

Ring Set Included

No

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Rod Length

5.700

Wrist Pin Quantity

4

Wrist Pin Retainer Quantity

8

Cylinder Head

Lima

Engine

Lima

Title

Professional - Ford, Lima, 3.830 in. Bore, Piston Set of 4

Engine - Web

Lima

Title - Web

Professional Piston Set of 4 Ford Lima - 3.830 in. Bore - 1.090 in. CH, -3.40 CC

Wrist Pin Part Number

S594

Wrist Pin Retainer Part Number

W5752

Wrist Pin Retainer Thickness

0.060
