Wiseco K0009B130 Big Block Chevy Quick 16 Forged Piston Set 45cc Dome +.030 Over

Manufacturer

Part Number

K0009B130
Black Friday Price

$1,137.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco K0009B130 is a Professional Series forged piston set engineered for Chevrolet Big Block (BBC) engines running 16-degree cylinder heads. Featuring a 45cc positive dome and a 1.155-inch compression height, this piston is purpose-built for high-compression, high-performance street and drag race applications. The +0.030-inch overbore designation (B130) makes these a direct choice for freshly bored BBC blocks.

Key Features:

  • Quick 16 Series: Designed specifically for use with conventional 16-degree cylinder heads from today's leading manufacturers
  • 45cc Dome: Positive dome volume engineered to deliver high compression ratios in big block Chevy applications
  • 1.155-inch Compression Height: Optimized for proper deck clearance and rod/stroke combinations
  • 2618 High-Strength Aluminum Alloy: Forged from aerospace-grade 2618 alloy for superior tensile strength and durability under extreme heat and pressure
  • ArmorGlide® Skirt Coating: Reduces operating friction, minimizes skirt and cylinder wall wear, and ensures quieter operation
  • Vertical Gas Ports: Improve ring seal for maximum cylinder pressure and power output
  • Anti-Detonation & Pressure Seal Grooves: Protects ring lands and maintains consistent ring seating under detonation events
  • .180-inch Tool Steel Wrist Pin with Double Spirolox®: Provides secure pin retention and precise fit
  • +0.030-inch Overbore (B130): Sized for standard BBC bores that have been bored .030 over
  • Rings Sold Separately

Engineered, forged, and machined in the USA, Wiseco's Professional Series pistons are built for serious engine builders who demand no-compromise performance. Whether you're building a naturally aspirated or nitrous-assisted big block, the K0009B130 delivers the strength and precision needed for heavy-duty race builds.

Products specifications

Piston Quantity

8

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Compression Height

1.155

Industry

Automotive

Product Market

Domestic

Engine Type

ICE

Engine

Big Block

Wrist Pin Material

5115

Product Series

Professional

Product Type

Engine Piston Set

Wrist Pin Outer Diameter

0.990

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Engine - Web

Big Block

Ring Set Included

No

Skirt Coating

Yes

Wrist Pin Included

Yes

Piston Volume

45.00

Wrist Pin Retainer Included

Yes

Wrist Pin Quantity

8

Wrist Pin Retainer Part Number

CS25

Bore Diameter

4.630

Make - Web

Chevy

Wrist Pin Part Number

S749

Title

Professional - Chevrolet, Big Block, 4.630 in. Bore, Piston Set of 8

Title - Web

Professional Chevy Big Block Piston Set of 8 - 4.630 in. Bore - 1.155 in. CH, 45.00 CC

Wrist Pin Retainer Quantity

32

Wrist Pin Retainer Style

Spiro Lock
