Wiseco 4591M07500 Big Bore Forged Piston Kit Compression - 75mm 13 1

(1994-1997 Kawasaki ZX900 Ninja ZX-9R)

Part of: Wiseco Pistons Forged Piston Kit Compression

Other options in this family: Wiseco Pistons 40071M05400 Wiseco Pistons 40109M08300 Wiseco Pistons 40078M07400 Wiseco Pistons 40086M09600 Wiseco Pistons 4629M07500

Manufacturer

Picture for manufacturer Wiseco Pistons

Part Number

4591M07500
7 reviews
Sale Price

$211.99

Estimated ship date Monday, November 23

Check out with

ApplePay
Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco 4591M07500 is a high-performance forged 4-stroke piston kit engineered for the Kawasaki ZX-9R (1994–1997). Expanding displacement to 950cc with a 75.00mm bore and 13:1 compression ratio, this big bore kit is purpose-built to maximize horsepower and torque for serious street and performance applications.

Key Features:

  • Forged high-silicon aluminum alloy construction for superior strength and long-term dependability
  • 75.00mm actual bore (2.00mm oversize from the standard 73.00mm bore) — cylinder boring required
  • 13:1 compression ratio for increased power output
  • Optimized piston skirt design for maximum horsepower and torque delivery
  • Dedicated forging engineered specifically for this engine application, optimizing the strength-to-weight ratio
  • Engineered, forged, and machined in the USA in Mentor, OH
  • Built to tight tolerances for reliable, consistent performance
  • Wiseco 4591M07500 forged piston (75mm, 13:1)
  • Wiseco 2953XG 75.00mm piston ring set
  • Wiseco S343 18.00mm wrist pin
  • Wiseco CW18 18mm round wire wrist pin circlips (pair)

Specifications:

  • Displacement: 950cc
  • Standard Bore: 73.00mm
  • Actual Bore: 75.00mm (2.00mm oversize)
  • Stroke: 53.74mm
  • Compression Ratio: 13:1
  • Wrist Pin Diameter: 18.00mm
  • Ring Set: 2953XG

Note: Cylinder boring is required for installation. This is an oversize piston kit. A head gasket (Wiseco W5440) is included. A base gasket (Wiseco W6051) is available separately.

Products specifications

Fits

1994-1997 Kawasaki ZX900 Ninja ZX-9R
