DBA DBA53002SLVXD 5000 Series Two-Piece Cross-Drilled Front Brake Rotor 390mm x 36mm

The DBA 5000 Series DBA53002SLVXD is a high-performance two-piece front brake rotor designed for Audi RS6 (C7, 2013-2017) and RS7 (4G, 2014-2017) models. This fully assembled rotor combines a high-carbon cast iron disc ring with an aerospace-grade T6061-T6 aluminum hat, secured with National Aerospace Standards (NAS) bolts for maximum reliability.

Key Features:

• 390mm outer diameter x 36mm thickness for exceptional stopping power
• Cross-drilled and dimpled (XD) design provides enhanced cooling and improved aesthetics while maintaining structural integrity
• Silver anodized aluminum hat reduces unsprung weight and minimizes heat transfer from disc to hub
• Patented Kangaroo Paw ventilation system with 144 diamond and teardrop pillars increases cooling efficiency up to 20% compared to conventional vented rotors
• Thermographic heat paint indicators change color at specific temperature thresholds to monitor rotor fatigue
• CBN (Cubic Boron Nitride) machined finish minimizes disc thickness variation
• Direct replacement design requires no vehicle modifications
• Replacement disc rings available separately to reuse aluminum hats

Recommended for high-performance street vehicles, track day applications, club racing, and rally sport. DBA's 5000 Series delivers the weight reduction benefits of a two-piece design while maintaining the thermal capacity needed for demanding driving conditions.
