ACL Bearings 4B2296HX-STD Race Series Connecting Rod Bearing - Set

The ACL Bearings 4B2296HX-STD is a Race Series connecting rod bearing set engineered for GM Ecotec engines, including 2.0L turbocharged/supercharged (LHU, LNF, LSJ), 2.2L (L61, LAP, LE8, Z22SE), and 2.4L (LAF, LE5, LE9, LEA, LUK) applications. Trusted by champions worldwide, ACL Race Series bearings are proven components in engines that have set records from sport compact drift racing to NASCAR competitions.

Race-Engineered Features:

• HX designation indicates 0.001" extra bearing clearance for standard journal crankshafts (bearings are 0.0005" thinner per half)
• High-strength overlay plate with reduced thickness for superior fatigue resistance
• Hardened steel backing on all rod bearings for improved support and housing retention
• Increased crush design for enhanced bearing retention under extreme conditions
• Flash plating eliminated from bearing backs to maximize heat transfer and housing grip
• Increased eccentricity compensates for bore distortion at high RPM

Specifications:

• Bearing Width: 0.799 inches
• Outside Diameter: 2.0519-2.0525 inches
• Shaft Diameter: 1.9291-1.9297 inches
• Maximum Wall Thickness: 0.0602 inches
• Standard size journal (STD)

ACL's unique combination of precision engineering, advanced metallurgy, and race-proven design delivers trimetal bearings with the endurance and capability to perform where others cannot. Designed to withstand higher RPM conditions and extreme loads, these bearings provide the reliability demanded by professional engine builders and performance enthusiasts.
