Skyjacker Suspension D692CDKS-X 6 Inch Suspension Lift Kit with ADX 2.0 Remote Reservoir Shocks

The Skyjacker D692CDKS-X is a complete 6-inch suspension lift system designed to accommodate larger 37-inch tires while improving ground clearance, ride height, and overall ride quality. This comprehensive kit includes front and rear leaf springs, leaf spring bushings, bushing sleeves, U-bolts, and rear blocks, along with premium ADX 2.0 Adventure Series remote reservoir shocks for superior performance on and off the road.

Softride Leaf Spring Technology:

• Shot-peened with hard steel pellets at very high velocities for enhanced durability
• Tapered leafs distribute loads more evenly and create more flex at the leaf ends
• Teflon wear pads between leafs and bolt style spring clips prevent binding and eliminate friction
• Provides 6-inch front and 6-inch rear lift (4.5-inch rear on Cummins diesel applications)

ADX 2.0 Remote Reservoir Shock Features:

• Off-road race-inspired full-displaced custom valve tuned system
• Impact extruded CNC machined T6061-T6 aluminum monotube dissipates heat and runs cooler versus traditional steel-bodied shocks
• Large 53.5mm body OD with 46mm ID bore size
• External remote reservoir separates nitrogen gas from oil with Internal Floating Piston (IFP)
• Teflon banded piston delivers smooth reaction and superior ride quality
• Provides consistent dampening, high-end performance, cooler running, more control, and improved driving comfort

This all-in lift kit delivers on-road refinement with off-road readiness, making it ideal for diesel truck owners seeking a proven, long-lasting suspension upgrade. The kit comes with all necessary mounting hardware and detailed installation instructions.
