Wiseco RED0079X140 RED Series Forged Piston 4.140 in. Bore 2618 Alloy

Manufacturer

Part Number

RED0079X140
Black Friday Price

$899.99

Estimated ship date Thursday, December 03

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0079X140 is a forged performance piston from the RED (Race Engineered Design) Series, built for racing and power-adder engine builds that need strength and durability.

Key Features:

  • Forged from 2618 aluminum alloy for the tensile strength needed in performance racing and power adder use
  • Strutted forging design for a high strength-to-weight ratio
  • ArmorGlide skirt coating reduces operating friction and noise, and reduces skirt and cylinder wear
  • Horizontal slot oiling in the pin bores helps lubricate the wrist pin and small end
  • Accumulator groove helps maintain consistent ring seal and power

A strong choice for drag racing, circle track and other high-output engine builds that need a dependable forged piston.

Products specifications

Piston Quantity

8

Rod Length

6.125

Stroke

4.000

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Engine

LS

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.140

Oil Ring Thickness

3.00

Compression Height

1.105

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Engine - Web

LS

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Piston Volume

-4.00

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Title

RED Series - Chevrolet, LS, 4.140 in. Bore, Piston Set of 8

Ring Quantity

8

Make - Web

Chevy

Ring Set Part Number

4137GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595

Title - Web

RED Series Chevy LS Piston Set of 8 - 4.140 in. Bore - 1.105 in. CH, -4.00 CC
