Wiseco RED0077X140 RED Series Forged Piston Set 4.140 in. Bore Chevy Small Block

Manufacturer

Part Number

RED0077X140
Black Friday Price

$899.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco RED0077X140 is part of the RED™ Series — Wiseco's Race Engineered Design™ forged piston line built for domestic V8 performance applications. Engineered, forged, and machined in the USA from 2618 aluminum alloy, these pistons deliver the tensile strength required for performance racing, power adder, and high-output engine builds.

Key Features:

  • Race Engineered Design™ (RED™): Dedicated, engine-specific strutted forgings optimize the strength-to-weight ratio for serious performance applications
  • 2618 Aluminum Construction: High-strength alloy provides superior resistance to heat and pressure in demanding racing and forced-induction environments
  • ArmorGlide® Skirt Coating: Reduces operating friction and noise while minimizing skirt and cylinder wall wear for extended service life
  • Horizontal Slot Wrist Pin Oiling: Maintains optimal lubrication at the wrist pin and small end of the connecting rod — critical for longevity under high RPM
  • Accumulator Groove: Helps maintain consistent ring seal and power output
  • Premium Rings Included: Each part number ships with a matched ring set — no additional sourcing required
  • 4.140 in. Bore Diameter: Sized for overbore builds on popular domestic V8 platforms

The RED™ Series is purpose-built for the cornerstone platforms of American performance — from drag racing to circle track competition. Wiseco's precision CNC machining ensures tight tolerances for consistent fit and optimum combustion efficiency. As the only U.S. manufacturer to forge their own aftermarket pistons, Wiseco brings over 80 years of motorsports expertise to every set.

Products specifications

Piston Quantity

8

Rod Length

6.125

Stroke

3.622

Wrist Pin Retainer Material

Chrome silicon

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Engine

LS

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.140

Oil Ring Thickness

3.00

Compression Height

1.294

Industry

Automotive

Product Market

Domestic

Second Compression Ring Thickness

1.20

Top Compression Ring Thickness

1.20

Engine Type

ICE

Wrist Pin Material

5115

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

EBAY Category ID

33623

Engine - Web

LS

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Retainer Included

Yes

Wrist Pin Retainer Style

Wire Lock

Piston Volume

-4.00

Product Series

RED Series

Wrist Pin Quantity

8

Wrist Pin Retainer Quantity

16

Title

RED Series - Chevrolet, LS, 4.140 in. Bore, Piston Set of 8

Ring Quantity

8

Make - Web

Chevy

Title - Web

RED Series Chevy LS Piston Set of 8 - 4.140 in. Bore - 1.294 in. CH, -4.00 CC

Ring Set Part Number

4137GFX

Wrist Pin Part Number

S736

Wrist Pin Retainer Part Number

W5595
