Skyjacker F5451K3-H 4-Inch Suspension Lift Kit with ADX 2.0 Remote Reservoir Shocks

(2005-2007 Ford F-350 Super Duty)

Manufacturer

Part Number

F5451K3-H
Black Friday Price

$1,327.57

In Stock (8)

delivery box

Usually delivered within 2 days

free shipping

FREE SHIPPING

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Skyjacker F5451K3-H is a complete 4-inch suspension lift kit engineered specifically for 2005–2007 Ford F-350 Super Duty 4WD Diesel trucks. This comprehensive kit raises ride height, improves off-road capability, and delivers a smooth, controlled ride through Skyjacker's proven 2-Stage Variable Rate coil spring technology paired with high-performance ADX 2.0 Remote Reservoir shocks.

2-Stage Variable Rate Coil Springs:

  • First Flex Rate stage delivers a comfortable, compliant ride with increased articulation at full suspension droop
  • Second Ride Rate stage engages only after compression past the Flex Rate, resulting in a progressively firmer, smoother ride under load

ADX 2.0 Remote Reservoir Shocks:

  • Front and rear ADX 2.0 Adventure Series Remote Reservoir Aluminum Monotube Shocks included
  • Race-inspired full-displaced Custom Valve Tuned valving system for consistent damping performance
  • High-pressure nitrogen gas with Internal Floating Piston (IFP) technology for the fastest shock response
  • Impact extruded CNC machined T6061-T6 aluminum monotube for superior heat dissipation versus traditional steel-bodied shocks
  • Large 53.5mm body OD with 46mm ID bore size for quicker reaction and smoothest ride possible
  • Teflon banded piston for smooth, stable performance across all terrain types
  • 2-year warranty on ADX 2.0 shocks

Complete Kit Includes:

  • 2-Stage Variable Rate front coil springs
  • Radius arm drop brackets — lowers OEM radius arm mounts at the frame to maintain correct caster specifications
  • Ultra heavy-duty track bar relocation bracket — captures the front crossmember on both sides to keep the axle centered
  • Hydro steering stabilizer and relocation bracket
  • Sway bar end links — realigns front sway bar working angle for maximum sway control
  • Bump stop drop spacers — repositions front bump stops
  • Front brake line brackets and braided stainless steel brake lines
  • 3.5-inch rear block and U-bolt kit for a more level stance
  • Carrier bearing lowering kit — corrects driveline angles to eliminate driveshaft vibration

Important Notes:

  • Diesel engines only — does not fit models with a gas engine
  • Pitman arm FA450 is required (sold separately)
  • If equipped with a rear sway bar, order extended end links SBE404 (sold separately)

Together, this complete kit maintains factory geometry angles, alignment specifications, and structural strength, giving your Super Duty the lifted stance and off-road performance it deserves.

Products specifications

Fits

2005-2007 Ford F-350 Super Duty

Prop 65

Yes

Lift/Drop Height

4 in.
