TiAL 005125 V60 60mm External Wastegate Black 1.14 Bar 16.53 PSI

The TiAL V60 60mm external wastegate is the largest and highest-flowing wastegate in the TiAL Sport lineup, engineered for maximum boost control in extreme high-performance turbocharged applications. This precision-crafted unit delivers dead-on accuracy in controlling boost pressure and turbine flow under the most demanding conditions, making it a favorite in drag racing, road racing, and high-horsepower street builds.

Key Features:

• 60mm valve diameter for maximum flow capacity - flows 330 CFM at 1 PSI differential pressure
• High-temp NiCrFe based alloy valve with 347 stainless steel valve housing for exceptional durability
• 17-7 PH stainless steel actuator spring rated to 900°F (483°C) resists pressure relaxation at high temperatures
• High-temperature silicone Nomex reinforced actuator diaphragm
• Nitronic 60 stainless steel valve seat and valve bushing for wear resistance
• Black anodized aluminum actuator housing
• Pre-set to 1.14 bar (16.53 PSI) spring pressure
• V-band inlet and outlet connections with 304L stainless steel weld flanges
• All stainless steel hardware included
• Racing valve stem with wear coating resistant to corrosive lead oxides from racing fuels

This wastegate includes the V60 assembly, valve seat, inlet and outlet V-band clamps, inlet and outlet flanges, air fittings, and all necessary stainless steel hardware for installation. Compatible with both leaded racing fuel and pump gas applications.
