TiAL 005103 External Wastegate Bar - V50 50mm 1.4 Silver

The TiAL Sport V50 External Wastegate is a high-performance 50mm boost control solution engineered for demanding turbocharged applications. This model features a 1.4 bar (20.3 PSI) spring pressure and silver anodized finish, combining precise boost control with exceptional durability.

Key Features:

• 50mm valve diameter for high-flow capacity and accurate boost control
• High-temperature alloy valve with stainless steel valve housing for extended service life
• CNC-machined billet aluminum actuator housing with silver anodized finish
• Nomex-reinforced silicone diaphragm for high-temperature durability
• 17-7 PH stainless steel actuator spring maintains consistent pressure at elevated temperatures
• Nitronic 60 stainless steel valve guides and seats for superior corrosion and galling resistance
• Dual-port diaphragm chamber with M10 signal ports for precise boost control under all conditions
• TiAL-specific valve stem coating with rigorously tested wear resistance
• V-band clamps and 304L stainless steel mating flanges included

The V50 shares the same compact form factor as the legendary V60 but offers a smaller valve size ideal for applications sensitive to exhaust manifold pressure-induced valve lift. Popular in both drag racing and road racing, this wastegate is fully engineered and manufactured in-house by TiAL Sport using proprietary alloys and the highest quality stainless steel and aluminum components.

Note: This product is not CARB compliant and not legal for sale or use in California.
