TiAL 005056 External Wastegate Bar Purple - V50 50mm 1.18

The TiAL Sport 005056 is a high-performance V50 external wastegate featuring a 50mm valve designed for precision boost control in demanding turbocharged applications. This wastegate comes configured with a 1.18 bar (17.11 PSI) spring and a purple anodized billet aluminum actuator housing.

Key Features:

• 50mm valve size optimized for EMAP-sensitive applications
• High-temperature alloy valve and stainless steel valve housing for extended durability
• CNC-machined billet aluminum actuator housing with purple anodized finish
• 17-7 PH stainless steel actuator spring rated at 1.18 bar (17.11 PSI)
• High-temperature silicone reinforced actuator diaphragm
• Nitronic 60 stainless steel valve guides and seats for superior wear and galling resistance
• Stainless steel V-band clamps and flanges included
• CNC-machined stainless steel and aluminum air fittings

The V50 shares the same compact form factor as the legendary TiAL V60 but offers a smaller valve size for applications sensitive to exhaust manifold pressure-induced valve lift. Trusted by drag racing and road racing professionals, this wastegate delivers dead-on boost accuracy in the most demanding situations. All TiAL wastegates are designed to optimize actuator-to-valve area ratio for maximum control and wide dynamic flow capacity.
