TiAL 005041 V50 Wastegate 50mm 0.95 Bar Purple

The TiAL 005041 V50 Wastegate is a high-performance 50mm external wastegate designed for precision boost control in turbocharged applications. Featuring a 0.95 bar (13.78 PSI) spring base pressure and distinctive purple anodized finish, this wastegate delivers accurate boost regulation in demanding racing and performance conditions.

Key Features:

• 50mm valve size optimized for applications sensitive to exhaust manifold pressure-induced valve lift
• 0.95 bar (13.78 PSI) spring base pressure with 17-7 PH stainless steel actuator spring for consistent pressure at elevated temperatures
• High-temperature alloy valve with stainless steel valve housing for extended product life
• High-temperature silicone reinforced actuator diaphragm for durability
• Lightweight billet aluminum actuator housing with purple anodized finish
• Stainless steel valve seat and valve bushing construction
• Includes SS band V-clamps and flanges with CNC-machined stainless steel and aluminum air fittings

The V50 shares the same proven form factor as TiAL's legendary V60 wastegate but offers a smaller valve diameter for superior control in boost-sensitive builds. Popular in both drag racing and road racing applications, this wastegate provides dead-on accuracy and wide dynamic flow capacity through its optimized actuator-to-valve area ratio.
