Wiseco K0159B100 Quick 8 Series Forged Piston Set BBC Brodix SR20 +23cc 1.120 CH

The Wiseco K0159B100 is a Quick 8 Series forged piston set engineered for high-performance Big Block Chevrolet engines built around Brodix SR20 cylinder heads. Featuring a +23cc hollow dome, a 1.120" compression height, and a 4.600" bore, these pistons are purpose-built for serious street/strip and drag race applications targeting a 13.7:1 compression ratio.

Crafted from 2618 high-strength aluminum alloy, the K0159B100 delivers superior fatigue resistance under the extreme thermal and mechanical loads of high-compression, high-RPM race engines. The strutted skirt design keeps weight low while maintaining stability under load. Wiseco's proprietary ArmorGlide® skirt coating reduces friction and improves scuff resistance during break-in and beyond.

Key Features:

• Quick 8 Series hollow dome design — +23cc dome volume
• 1.120" compression height — designed for BBC 565 stroker combinations
• 4.600" bore diameter
• 2618 high-strength forged aluminum alloy construction
• ArmorGlide® skirt coating for reduced friction and improved wear resistance
• Vertical gas ports for enhanced ring seal and combustion efficiency
• Anti-detonation and pressure seal grooves
• .180" tool steel wall wrist pin with Double Spirolox® retainers — included (Pin P/N: S726, .990" x 2.930")
• Ring grooves: .043" / .043" / 3.0mm — rings sold separately
• Brodix SR20 cylinder head compatible

Ringsets are sold separately. Wiseco's Quick 8 Series is a trusted choice for professional engine builders constructing competitive Big Block Chevy race engines with Brodix SR20 heads.
