Wiseco K0421X3905 Chevrolet LS 3.900 Stroker Forged Piston Set 3.905 in. Bore

Manufacturer

Part Number

K0421X3905
Black Friday Price

$1,122.99

Estimated ship date Saturday, December 05

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco K0421X3905 is a Professional Series forged piston set engineered for Chevrolet LS 3.900-inch stroker builds.

These LS stroker pistons are geometrically optimized for the 3.900-inch stroke rod angle, resulting in smoother, more precise operation that reduces bore distortion, minimizes crank and rod stress, and maintains a more consistent ring seal throughout the power stroke. The increased compression height design further reduces piston rock and improves cylinder stability for reliable, repeatable performance.

Key Features:

  • Forged in-house from 2618 high tensile strength aluminum alloy for superior durability under boost, nitrous, and naturally aspirated high-output conditions
  • ArmorGlide® skirt coating provides seizure resistance, reduced friction, and quieter operation
  • Includes H13 wrist pins and a 1.2mm / 1.2mm / 3.0mm GFX ring pack for a complete, race-ready assembly
  • Fully machined crown with precision ring grooves for optimal ring seal
  • Compatible with LS1, LS2, LS3, LS6, and LS9 valve pocket configurations
  • Engineered, forged, and machined in the USA at Wiseco's Mentor, Ohio facility

Specifications:

  • Bore: 3.905 in.
  • Compression Height: 1.165 in.
  • Pin Diameter: 0.927 in.
  • Stroke: 3.900 in.
  • Ring Pack: 1.2mm / 1.2mm / 3.0mm GFX
  • Material: 2618 Aluminum Alloy

Wiseco's Professional Series represents a no-compromise approach to piston design — suited for heavy to severe duty race builds where consistency, strength, and precision are non-negotiable. Built for racers, by racers.

Products specifications

Piston Quantity

8

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Engine

LS

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

3.905

Compression Height

1.165

Industry

Automotive

Product Market

Domestic

Engine Type

ICE

Oil Ring Thickness

3

Product Series

Professional

Product Type

Engine Piston Set

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-9.00

Second Compression Ring Thickness

1.2

Top Compression Ring Thickness

1.2

EBAY Category ID

33623

Engine - Web

LS

Make - Web

Chevrolet

Ring Set Included

Yes

Skirt Coating

Yes

Wrist Pin Included

Yes

Wrist Pin Material

9310

Title

Wiseco - Chevrolet, LS, 3.905 in. Bore, Piston Set of 8

Forging Type

Spherical Dish

Title - Web

Professional Chevy LS Piston Set of 8 - 3.905 in. Bore - 1.165 .in CH, -9.00 CC
