Wiseco K0066A6 Professional Series Forged Dish Piston Set Chevy SB 23-Degree Forced Induction

Manufacturer

Part Number

K0066A6
Black Friday Price

$1,058.99

Estimated ship date Friday, December 04

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The Wiseco K0066A6 is a Professional Series forged dish piston set engineered specifically for Chevrolet small block engines with 23-degree cylinder heads running forced induction — turbocharger or supercharger applications.

Key Features:

  • Forged aluminum construction — forged from 2618 or 4032 aluminum alloy for maximum strength and durability under extreme heat and pressure
  • Dish crown design — optimized for forced induction applications, reducing compression ratio to work safely with boost
  • 4.060 in. (103.124 mm) bore — precision CNC-machined to tight tolerances for consistent fit and performance
  • 3.480 in. stroke compatibility — designed for stroked small block Chevy builds
  • 0.300 in. top ring land thickness — reinforced ring land designed to withstand the additional cylinder pressures generated by turbo and supercharged engines
  • 23-degree cylinder head compatible — matches the standard Chevrolet small block 23-degree valve angle head configuration
  • Chromoly wrist pins and Spirolox retainers included — premium hardware included for a complete, ready-to-install piston assembly
  • Rings not included — piston rings sold separately

Wiseco Professional Series pistons are precision CNC-machined after forging to achieve intricate final configurations under strict tolerances. With over 80 years of forging expertise, Wiseco manufactures these pistons in the USA, making the K0066A6 a proven choice for serious small block Chevy forced induction builds — from street/strip combos to dedicated race engines.

Products specifications

Piston Quantity

8

Stroke

3.480

Wrist Pin Style

Floating

Make

Chevrolet

Piston Material

2618

Wrist Pin Outer Diameter

0.927

Rod Length

6.000

Prop 65

WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Bore Diameter

4.060

Compression Height

1.250

Industry

Automotive

Product Market

Domestic

Engine

Small Block

Engine Type

ICE

Wrist Pin Material

5115

Product Series

Professional

Product Type

Engine Piston Set

Forging Type

Strutted

Out of Stock Message

Estimated Shipped Date 3-4 Weeks

Piston Volume

-13.00

EBAY Category ID

33623

Engine - Web

Small Block Gen I

Make - Web

Chevrolet

Ring Set Included

No

Skirt Coating

Yes

Wrist Pin Included

Yes

Title

Wiseco - Chevrolet, Small Block, 4.060 in. Bore, Piston Set of 8

Title - Web

Professional Chevy Small Block Piston Set of 8 - 4.060 in. Bore - 1.250 .in CH, -13.00 CC
