HPS Performance Products FKM-9F-032-BLUE FKM Silicone Hose 5/16" ID 9 Ft Blue Oil Resistant

The HPS Performance FKM-9F-032-BLUE is a high-temperature, oil-resistant silicone hose built for demanding underhood applications. FKM (fluoroelastomer) lined, this hose solves a common problem: standard silicone hoses degrade when exposed to fuel, oil, and other aggressive automotive fluids. The fluoroelastomer inner liner creates a barrier that minimizes fluid permeation, evaporation, and hose degradation, delivering performance that plain silicone simply cannot match.

Featuring 1-ply polyester reinforcement and a UV- and ozone-resistant outer jacket, this hose is engineered to hold up in harsh engine bay environments. It ships as a 9-foot length with a 5/16" (8mm) inside diameter, providing plenty of material for custom routing and trimming to fit.

Key Features:

• FKM (Fluoroelastomer) Inner Liner — superior resistance to gasoline, diesel, mineral oil, synthetic hydraulic fluids, aromatics, and many organic solvents
• Temperature Range: -65°F to +350°F (-54°C to +177°C)
• Maximum Working Pressure (fuel line use): 55 psi
• Maximum Working Pressure (non-fuel line use): 90 psi
• Inside Diameter: 5/16" (8mm)
• Outside Diameter: 5/8" (16mm)
• Wall Thickness: 4mm ±0.2mm
• Minimum Bend Radius: 1-1/4"
• Length: 9 feet
• Color: Blue
• 1-ply polyester reinforced construction
• UV and ozone resistant outer silicone jacket

Recommended Applications:

• Fuel Return Lines
• Fuel Ventilation
• Crankcase Ventilation
• Turbo Oil Return
• Power Steering Return
• Automatic Transmission Oil Cooler Lines

Important Limitations:

• NOT for continuous handling of alcohol-based fuels
• NOT for use fully submerged in fuel
• NOT for fuel line applications exceeding 55 psi working pressure
