Metra AXDSPL-FD2 DSP Lite Package with T-Harness for Ford 2011-Up

The Metra AXDSPL-FD2 is a cost-effective digital signal processor package designed to upgrade the sound system in select Ford vehicles from 2011 and up. This complete package includes the AXDSP-L (DSP Lite) processor and a vehicle-specific T-harness for streamlined installation.

Audio Signal Processing:

This DSP interface works with both OEM factory radios and aftermarket head units to convert fixed-level or digitally controlled analog audio into 6 channels of clean analog signal output. The processor features 4 inputs and 6 outputs, including dedicated channels for front, rear, and subwoofer connections, allowing you to integrate aftermarket amplifiers or additional signal processors into your factory audio system.

Complete Tuning Control:

• 15-band graphic equalizer for precise sound tuning
• Selectable high-pass, low-pass, or bandpass filters on each channel
• Adjustable filter slope options: 12dB, 24dB, 36dB, or 48dB per octave
• Independent channel delay up to 10ms for front and rear outputs
• Clipping detection and limiting circuits for signal protection
• Smart device control via mobile app (tablets and smartphones)
• Password protection capability for installed settings

Factory Feature Retention:

Unlike traditional DSP units, the AXDSPL-FD2 retains critical factory vehicle functions including chime control, OEM voice prompts, and parking sonar sensors. This ensures you maintain full functionality of your Ford's integrated systems while upgrading your audio quality.

Installation:

The included vehicle-specific T-harness simplifies installation by eliminating the need for wire splicing in most applications. The package is designed to work with both amplified and non-amplified Ford factory audio systems.

Package Includes:

• AXDSP-L digital signal processor
• Ford-specific T-harness
• Amp bypass harness
