Skyjacker F5852KS3-H 8.5 Inch Suspension Lift Kit with Hydro Shocks

The Skyjacker F5852KS3-H is an 8.5-inch suspension lift system that re-engineers the Super Duty's suspension via an impressive 4-Link Conversion designed specifically for 2005-2007 Ford F-250/F-350 Super Duty 4WD diesel models. This comprehensive kit transforms your truck's off-road capability while maintaining superior ride quality and handling characteristics.

4-Link Conversion System:

• Replaces OEM radius arms with integrated radius arm drop brackets plus upper and lower adjustable control arms formed from 2-inch OD x 0.250 wall DOM tubing
• Adjustability allows proper caster settings to improve handling
• Flex Links feature forked clevis end at lower axle mount and 1-1/4 inch forged rod end with steel encased rubber bushing at upper bracket mount
• Drop brackets lower the rear mounts at the frame to maintain correct caster specifications for proper alignment

Spring and Suspension Components:

• Specifically engineered 2-Stage Variable Rate coil springs for Super Duty F350 4WD Diesel motors deliver smooth controlled comfortable ride
• Softride Technology leaf springs with tapered leafs distribute loads evenly, featuring Teflon wear pads and bolt style spring clips to prevent binding and eliminate friction
• Ultra heavy-duty track bar relocation bracket captures front crossmember on both sides to prevent movement and keep axle centered
• Front sway bar links realign sway bar, drop brackets reposition front bump stops, and braided stainless steel brake lines correct brake line positioning

Hydro 7000 Series Shocks:

Includes four Hydro shocks offering high quality shock absorption with true velocity sensitive valving that produces stable, controlled resistance for better handling, improved stability, and maximum comfort. Kit also includes heavy-duty steering stabilizer relocation bracket and Hydro steering stabilizer.

Complete Kit Includes:

• Coil spring set with 2-stage variable rate design
• 4-Link conversion kit with adjustable control arms
• Rear Softride leaf springs
• Four Hydro 7000 series shocks
• Track bar bracket and steering stabilizer
• Sway bar links and brake line brackets
• Radius arm brackets and U-bolts
• All necessary mounting hardware

Important Notes:

• Does not fit models with gas engine - diesel only
• Part #FA450 Pitman Arm is required (sold separately)
• If equipped with rear sway bar, order extended end links Part #SBE406
• Professional installation recommended
