Skyjacker Suspension F5852K-X Lift Kit with ADX Remote Reservoir Shocks - 8.5 Inch 4-Link 2.0

The Skyjacker F5852K-X transforms the Ford Super Duty suspension with an impressive 8.5-inch 4-Link Conversion system that replaces factory radius arms with integrated drop brackets and adjustable upper and lower control arms. Specifically engineered for Super Duty F250 4WD Diesel applications, this complete lift kit delivers exceptional ground clearance while maintaining proper suspension geometry and ride quality.

Advanced 4-Link Suspension System:

• Adjustable Flex Links control arms formed from 2-inch OD x 0.250 wall DOM tubing for maximum strength
• Adjustability allows proper caster settings to improve handling, with forked clevis ends at lower axle mounts
• Upper bracket mounts feature 1-1/4 inch forged rod ends with steel encased rubber bushings
• Drop brackets lower rear frame mounts to maintain correct caster specifications for proper alignment
• 2-Stage Variable Rate coil springs specifically tuned for diesel engine weight

Premium ADX 2.0 Remote Reservoir Shocks:

• Race-inspired full-displaced custom valve tuned system delivers consistent dampening, high-end performance, and improved driving comfort
• Impact extruded CNC machined T6061-T6 aluminum monotube dissipates heat and runs cooler than steel-bodied shocks while weighing less
• Features high pressure nitrogen gas with Internal Floating Piston Technology and 53.5mm body OD with 46mm ID bore size
• Engineered for higher speed applications while still performing excellently at crawl speeds
• Backed by a 2-year quality assurance warranty

This complete suspension lift kit includes all necessary mounting hardware and detailed installation instructions. Skyjacker Suspension Lift Kits provide a smooth, comfortable ride while responding to on or off-road conditions, helping you achieve the right height and clearance while maintaining factory ride quality and improving handling.
