Skyjacker F5651KS3-M 6-Inch Suspension Lift Kit with M95 Performance Shocks

The Skyjacker F5651KS3-M is a complete 6-inch suspension lift system engineered specifically for 2005–2007 Ford F-350 Super Duty 4WD diesel trucks. This comprehensive kit delivers increased ground clearance and improved off-road capability while maintaining factory geometry, alignment specifications, and structural integrity.

The kit includes Skyjacker's legendary Softride® variable-rate front coil springs, which use a two-stage flex rate design for a smooth, controlled ride on and off the road. Radius arm drop brackets reposition the OEM radius arm mounts at the frame to preserve correct caster specifications for proper alignment. An ultra heavy-duty track bar relocation bracket captures the front crossmember on both sides to keep the axle centered under all conditions.

Key Features:

• 6-inch front and rear suspension lift
• Softride® 2-stage variable-rate front coil springs for superior ride quality
• M95 monotube high-pressure performance shocks — front and rear
• Radius arm drop brackets to maintain correct caster and alignment
• Heavy-duty track bar relocation bracket to keep axle centered
• Extended sway bar end links to correct working angle and maximize sway control
• Stainless steel braided brake lines with relocation brackets
• Rear leaf springs and U-bolts included
• Bump stop spacers to safely limit suspension travel
• Steering stabilizer and relocation bracket included
• All components powder-coated black for corrosion resistance
• All necessary mounting hardware and detailed installation instructions included
• Limited lifetime warranty

Additional Notes: This kit is designed for diesel engine models only and does not fit gas-engine applications. Pitman Arm #FA450 is required and sold separately. If equipped with a rear sway bar, order extended end links #SBE405. If equipped with a Sterling rear axle, order rear U-bolt kit #U9B12R.
