MAHLE 930227870 PowerPak LS 4.070 Bore Flat Top Forged Piston & Ring Kit

Manufacturer

Part Number

930227870
Black Friday Price

$715.17

Estimated ship date Saturday, December 05

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The MAHLE 930227870 PowerPak Piston and Ring Kit is a complete, race-proven forged piston assembly engineered for high-performance LS-based engines. Designed around a 4.070" bore and 3.622" stroke with a 6.125" rod length, this kit targets builders constructing a 377 cubic inch LS combination using LSX-compatible cylinder heads including L92 and LS3 style heads.

Built from 4032 aluminum alloy, these forged pistons deliver excellent temperature stability and tighter cylinder-to-wall clearance tolerances compared to 2618 alloy alternatives — making them ideal for naturally aspirated builds and mild power adder applications such as small nitrous shots or light boost levels up to 10 psi. The -5.8cc flat-top dome with combination valve pockets provides broad head compatibility while targeting an approximate 10.2:1 compression ratio. Each piston weighs a lightweight 454 grams and uses a 0.927" wrist pin at a 1.304" compression height.

Key Features:

  • 4032 forged aluminum alloy for superior strength and dimensional stability
  • -5.8cc flat-top design with combination valve pockets — compatible with L92 and LS3 cylinder heads
  • GRAFAL® anti-friction skirt coating reduces drag, friction, scuffing, and bore wear
  • Phosphate dry lubricant coating on pin bores and ring grooves protects against micro-welding and galling during initial startup and break-in
  • Low-drag 1.0mm / 1.0mm / 2.0mm ring pack included for reduced friction and improved ring seal
  • Steel wrist pins and round wire locks included — complete kit, ready to install
  • Hand-deburred forgings machined to tight tolerances with fully machinable crown
  • Laser-etched part number and production batch information on each piston crown
  • Displacement: 377 CID | Bore: 4.070" | Stroke: 3.622" | Rod: 6.125" | Pin: 0.927" | CH: 1.304" | Weight: 454g | CR: ~10.2:1

MAHLE Motorsports is a globally recognized leader in piston technology with over 90 years of racing heritage. The PowerPak line brings professional-grade forged piston technology to performance street and track applications, trusted by top race teams and weekend builders alike.

Products specifications

Piston Material

Forged, 4032

Prop 65

WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov

Pin Material

Steel

Piston Ring Thickness

1.0mm, 1.0mm, 2.0mm

Pin Style

Floating

Piston Mass

454g

Clip Style

Round Wire
