MAHLE 930227530-1 LSX Combo PowerPak Flat Top Piston - LS 6.0L 4.030" Bore 408ci 2618 Alloy (Single)

Manufacturer

Part Number

930227530-1
Black Friday Price

$111.21

Estimated ship date Saturday, December 05

Authorize Seller Badge
No Hassle Returns

No Hassle Returns

Live-in-stock inventory

Live-in-stock inventory

Fitment guaranteed

Fitment guaranteed

Product Details

The MAHLE Motorsport 930227530-1 is a single forged flat top piston from the LSX Combo PowerPak series, engineered for high-performance Chevrolet LS 6.0L stroker engine builds. Designed for a 408 cubic inch displacement configuration, this piston features a 4.030" bore diameter, 4.000" stroke, and a 6.125" connecting rod length for a purpose-built stroker application.

The LSX Combo valve pocket design offers maximum versatility, with pockets compatible with LS1/LS2/LS6-style cathedral port heads as well as LS3/L92-style rectangular port heads, eliminating the need to match your piston selection to a specific cylinder head family. The flat top crown with a -5.8cc dome volume delivers an aggressive 11.6:1 compression ratio, making it well-suited for naturally aspirated, nitrous, or power-adder builds.

Key Features:

  • 2618 Forged Aluminum Alloy construction for superior strength and detonation resistance in high-output applications
  • Flat top crown with -5.8cc volume and 11.6:1 compression ratio
  • 4.030" bore x 1.110" compression distance (RCH)
  • 0.927" wrist pin diameter for high-load rod and pin applications
  • Lightweight design at approximately 423g per piston for reduced rotating mass
  • LSX Combo valve pockets compatible with LS1/2/6 cathedral port and LS3/L92 rectangular port cylinder heads
  • Phosphate coating on exterior, pin bores, and ring grooves provides dry film lubrication and corrosion resistance
  • Grafal anti-friction skirt coating reduces wear, scuffing, drag, and piston noise
  • Designed for a 408ci stroker combination: 4.030" bore / 4.000" stroke / 6.125" rod
  • Sold as a single piston (ea)

MAHLE Motorsport PowerPak pistons are manufactured to exacting tolerances using MAHLE's own precision equipment, backed by over 100 years of OE and motorsport engineering experience. This piston is intended for race and off-road use and is not emissions-legal for street use in all states.

Products specifications

Prop 65

WARNING: Cancer and Reproductive Harm - www.p65warnings.ca.gov

Pin Style

Floating

Piston Ring Thickness

1.0mm, 1.0mm, 2.0mm

Clip Style

Round Wire

Piston Material

Forged, 2618

Piston Mass

423g

Pin Material

Steel
